Working Pressure :- 50 Bar For Aluminium/ 150 Bar For Stainless Steel
Accuracy :- +/- 0.5% Reading
Temperature :- -20 to 80 Celsius
Input Power :- 5v DC to 24v DC
Pulse Out Put Sensor :- Output Signal NPN Pulse Output
MOC :- Aluminium / SS
Gear :- Aluminium / SS
Process Connection :- BSP Threaded As per Standard
Pressure Drop :- 0.02 - 0.1 KG/cm²
Accuracy :- ± 0.5%.Of Flow Rate
Repeatability :- ± 1.0% Of Flow Rate
Seals :- Viton Withstand Against Max. 80 Degree Temp.
Input Supply :- 230v Ac.
Repeatability :- ± 0.1%.
Accuracy :- +/-0.5% Of F.S.
Output. Std. :- 4 to 20 mA, RS 485, Relay
Flow Range :- As Per Specification.
Industrial applications of our Oval Gear Meters : Highly versatile, Our Oval Gear Meters can easily handle any downstream liquid flow measurement with accuracy and reliability. Our series of Oval Gear Meters are widely used across different sectors. Some of the common applications include:
Approved and extensively used for custody transfer
Terminal Automation
Diesel Unloading
Chemical Unloading
Solvent Batching
Bowser dispensing
Consumption Monitoring
We offer world-class flow measurement solutions, including oval gear flow meter, magnetic flow meter and oval gear digital meter. To buy flow measurement solutions and to know how these industrial equipment can help your business, get in touch with us and find out how we can help your business.
| PART NO. | LINE SIZE | THREAD SIZE | FLOW RANGE |
| MI-OGFM-003 | 3mm | ¼” BSP | 0.5 – 35 L/H |
| MI-OGFM-006 | 6mm | ¼” BSP | 5 – 150 L/H |
| MI-OGFM-009 | 9mm | 3/8” BSP | 15 – 300 L/H |
| MI-OGFM-013 | 13mm | ½” BSP | 100 -1500 L/H |
| MI-OGFM-019 | 19mm | ¾” BSP | 200 – 2200 L/H |
| MI-OGFM-025 | 25mm | 1” BSP | 500 – 4000 L/H |
| MI-OGFM-040 | 40mm | 1 ½” BSP | 1000 – 10000 L/H |
| MI-OGFM-050 | 50mm | 2” BSP | 5000 – 20000 L/H |
| MI-OGFM-065 | 65mm | 2.5” BSP | 5000 – 30000 L/H |
| MI-OGFM-080 | 80mm | 3” BSP | 10000 – 50000 L/H |
| MI-OGFM-100 | 100mm | 4” BSP | 20000 – 75000 L/H |
