Housing :- Cast Aluminum, Weatherproof Stoving enamel Painted suitable for back panel/ Well
Mounting
Cable Entries :- 3 Nos. of ½” BSP
Main Supply :- 110 or 230V AC/ 24 V DC (15 to 10%) 50 Hz (As specified Order)
Relay Output :- One set of Potential free change over contacts rated at 6A 230V AC, 50 Hz for non
inductive load
Power Consumption :- 5VA Approx.
Fail-Safe Mode :- High or Low field selectable
Response Time :- 0.5 seconds
Switching Delay :- 0.5 to 20 seconds for probe covered and uncovered condition (on request)
Maximum Sensitivity :- 25µ Siemens
Operating Mode :- A) Single Point Switching B) Two-point Switching with pump control logic
Indication :- Red LED for Alarm, Green LED for Normal
Operating Temp. :- 20℃ to + 60℃. Weight :- 2 Kg Probe
Mounting :- ½ to 1 ½” BSP Screwed (Flange mounting on request)
Voltage :- 12V AC (across probe & tank wall/grounding electrode)
